Description
The Modular Systems DSBD7-1800R/A is a 1800mm right-inlet double sink dishwasher bench that positions the dishwasher inlet and two stainless steel sinks on the right side when facing the bench, delivering a space-efficient pre-wash and rinse station purpose-built for commercial kitchens.
Why operators choose the DSBD7-1800R/A
-
Right-inlet configuration — sinks and dishwasher inlet positioned on the right for ergonomic workflow with right-feed machines
-
Double bowl design — two fully welded 450×450×300mm bowls, polished inside and out, with 90mm Ø drain holes for fast drainage
-
SUS304 (18/8) stainless construction — 1.2mm gauge benchtop lined with 15mm XPS board and S/S U-channel reinforcements for rigidity
-
Integrated splashback — 150mm high, 30mm thick, bevelled and fully enclosed to protect walls and simplify cleaning
-
Flat-pack delivery with tools included — ships in compact packaging (1870×770×530mm) and assembles with supplied instruction manual and tools
Specifications
| Brand |
Modular Systems |
| Model / MPN |
DSBD7-1800R/A |
| Type |
Dishwasher Double Sink |
| Width |
1800 mm |
| Depth |
700 mm |
| Height |
900 mm |
| Bowl Size |
450mm W × 450mm D × 300mm H |
| Drain Hole Diameter |
90 mm Ø |
| Number of Bowls |
2 |
| Inlet Side |
Right (sinks on right when facing bench) |
| Material Grade |
SUS304 (18/8) Stainless Steel |
| Material Gauge |
1.2 mm |
| Wet Edge |
15 mm |
| Splashback Height |
150 mm |
| Splashback Thickness |
30 mm |
| Leg Diameter |
42 mm Ø (adjustable, polished disc feet) |
| Legs per Bench |
4 |
| Net Weight |
45.45 kg |
| Packed Dimensions |
1870(W) × 770(D) × 530(H) mm |
| Warranty |
24 months — 2 Years Parts Only |
Venue suitability: Ideal for restaurants, cafes, hotels, aged care facilities, school canteens, and any commercial kitchen requiring a compact right-inlet dishwasher pre-wash station. The 1800mm bench suits medium-volume operations where counter space is at a premium but throughput demands a double-bowl scrapping and rinsing setup.
Explore our full range of Dishwasher Inlet Sinks & Outlet Benches or browse all Modular Systems products for matching benches and accessories.
Installation & delivery: Supplied flat-packed with an instruction manual and assembly tools. Four fully adjustable stainless steel legs are included; castor kits are available separately. Ships Australia-wide via freight — please allow standard lead time for delivery to your state.
Frequently asked questions
What does 'right inlet' mean?
When standing in front of the bench, the dishwasher inlet connection and both sinks are on the right-hand side. The left side provides a clean landing zone for freshly washed items.
What is the bowl size?
Each of the two bowls measures 450mm wide × 450mm deep × 300mm high, with a 90mm Ø drain hole for efficient water removal.
Is the splashback included?
Yes. A 150mm high, 30mm thick stainless steel splashback is supplied as an integral part of the bench — bevelled and fully enclosed.
What stainless steel grade is used?
The benchtop is SUS304 (18/8) stainless steel at 1.2mm gauge, with XPS board underlining and stainless U-channel reinforcements for structural rigidity.
What is the warranty?
The DSBD7-1800R/A carries a 2-year parts-only warranty from Modular Systems.
SKU: DSBD7-1800R/A
In Stock
