Description
The FED-X XF200SG is an underbench glass door display freezer that keeps frozen product at -22 to -18°C in a compact, under-counter footprint — ideal for bars, cafes, service counters, and grab-and-go displays where visibility and tight floorspace are both priorities.
Why operators choose the XF200SG
-
Glass door visibility — customers see frozen product at a glance; no need to open the door, reducing cold-air loss.
-
Compact underbench profile — 600 × 585 × 850 mm fits neatly beneath service counters and bars with no wasted floor space.
-
Digital temperature control & read-out — precise set-and-monitor operation, with temperature locked between -22 and -18°C.
-
50 mm high-density insulation — CFC & HCFC-free foam maintains stable temps even in a 25°C ambient kitchen environment.
-
Stainless steel exterior with rounded internal corners — commercial-grade build, easy to wipe down, hygienic by design.
-
Locking glass door with recessed handle — castors on rear and adjustable legs in front for easy repositioning and levelling.
-
Natural R290 refrigerant — low-GWP, eco-friendly, with energy consumption of just 3.649 kWh/24h.
Specifications
| Brand |
FED-X |
| Model / MPN |
XF200SG |
| Type |
Underbench Glass Door Display Freezer |
| Capacity (Net) |
113 L |
| Gross Volume |
120 L |
| Temperature Range |
-22 to -18°C |
| Max Ambient Temperature |
25°C / 60% RH |
| Refrigerant |
R290 (natural, eco-friendly) |
| Doors |
1 × Hinged Glass Door (locking, recessed handle) |
| Exterior Material |
Stainless Steel |
| Insulation |
50 mm high-density, CFC & HCFC-free |
| Power |
240V / 332W / 10A |
| Energy Consumption |
3.649 kWh/24h |
| Product Dimensions (W × D × H) |
600 × 585 × 850 mm |
| Packed Dimensions (W × D × H) |
646 × 642 × 990 mm |
| Net Weight |
50 kg |
| Feet / Mobility |
Castors (rear) + adjustable legs (front) |
| Country of Manufacture |
China |
| Warranty |
2 Years Parts & Labour + 2 Years Parts Only (with Product Registration) |
Venue suitability: Well suited to bars, cafes, convenience stores, food service counters, and grab-and-go retail displays requiring a compact underbench freezer with product visibility. The 25°C maximum ambient rating covers most commercial kitchen and front-of-house environments.
Explore the full Under Bench Freezers collection or browse all FED-X refrigeration for companion units.
Installation & delivery: Plug-in 240V single-phase connection — no trade installation required. Castors allow easy positioning once on-site. Allow clearance at the rear ventilation grille. Dispatched Australia-wide.
Frequently asked questions
What is the usable capacity of the XF200SG?
The net usable capacity is 113 L. The gross internal volume is 120 L; the difference accounts for the fixed shelf structure and insulation intrusion.
Is this unit suitable for storing ice cream and frozen food?
Yes. The XF200SG operates at -22 to -18°C, which meets the requirements for storing commercially frozen products including ice cream, frozen meals, and ice.
Does the door lock?
Yes. The glass door features a locking mechanism with a recessed handle, appropriate for front-of-house environments where access control is required.
What refrigerant does the XF200SG use?
It uses R290 (propane), a natural, low-GWP refrigerant that is CFC and HCFC-free. This is eco-friendly and complies with current environmental standards.
Can this unit be used on castors permanently?
The XF200SG ships with castors at the rear and adjustable legs at the front. The adjustable legs allow levelling on uneven floors. For a fixed installation, ensure the rear castors are engaged with a brake if available, or secure as appropriate for your site.
SKU: XF200SG
In Stock
